Many cities & counties require building certification. We can
install this Metal Carport (Regular Style Roof) With 29 Gauge Horizontal
Roof on your level ground or existing concrete slab. Certified up to
140 MPH/30 PSF with the Standard 14 Gauge Steel Frame. We offer up to
170 MPH Wind Speed or up to 65 PSF Snow Load Certification in most
states we service for an additional charge.
All Stated Dimensions Are Wide By Long.
The roof panels used are 29 Gauge Rolled, Rib-Formed, Locked Seam steel panels. Eagle uses Becker's Paint with a Beckrypol Coating System that has a bright and colorful finish, and is available in 14 color choices. Beckrypol is a complete coating system, consisting of a corrosion resistant primer with a durable exterior topcoat that has a functional backer. This coating system provides optimum balance between visual properties and long term performance.
On the Regular Style and the Boxed Eave Style the standard way the roof panels are installed is horizontally. When the roof panels are installed horizontally, the ridges of the steel panels run parallel to the sides and top ridge of the structure. Water, snow, etc., will drain to the front and back of the structure, and may tend to pond on the roof. The maximum length of a horizontal panel is 31'. Any structure over 31' in length will have two horizontal panels seamed together at some place. On the Boxed Eave Style the roof panels can be installed vertically for an additional charge. On the Box Eave Style with the roof panels installed vertically, the ridges of the roof panels run from the top ridge of the structure to the sides, and has "Purlins", (an additional frame running lengthwise), to attach the vertical roof panels to. This roof configuration displaces water, snow, etc., much more efficiently and water will not pond on the roof. We strongly recommends the vertical roof on all structures over 31'. Vertical Roof Structures could be up to one foot shorter than specified length.
The standard frame used is 14 Gauge 2 1/2 Inch Galvanized Steel Tubing certified for 30 PSF snow load and 140 MPH wind gust if properly anchored as described below. The standard spacing of the frame legs/bows is 5 feet on center. There may be a small charge for engineering plans in some states if needed.
There are three anchoring types used for installation. The standard concrete anchor used is a traditional concrete wedge type anchor. If anchored to a proper footing this way, the building will be certified. An optional helical mobile home anchor or asphalt anchor is used and required for ground installation to achieve certification on a dirt, asphalt, or a gravel surface. A 30 inch rebar anchor is used when a structure is mounted directly to a dirt, asphalt, or a gravel surface, and not needing certification.
Please insure that the site designated for installation is as flat and square a surface as possible. We do not build over any structure without damage waivers signed and extra labor fees charged. Make sure site is clear of any obstructions. In order to provide you with affordable products with free installation, site preparation as well as building permits, are the responsibility of the customer and must be done before installation is attempted. If the site is not level and square then the structure will have to be installed "As Is". We can not anchor to solid rock. The anchors must be able to go into the ground if not anchored on concrete. Call 1st if you have any concerns.
This is a special order. Please only order if you have done all due diligence and due process.
No refunds of the down payment can be given on cancellations for any reason. The down payment is the restocking fee and is not refundable for any reason. The customer is responsible for any local permits, covenant searches, rights of way, set-back restrictions, site preparation, city or county ordinances etc. Delivery and installation should be within 2 to 8 weeks from time of order in almost all cases. This is why only a small portion of the sales price, (10% - $595.00 to $1,999.00, 12% - $2.000.00 to $3,999.00, 15% - $4.000.00 to $4,999.00, and 16% - $5,000.00 and up), is required to order. The balance, (84% to 90% of the sales price, plus the sales tax), is only paid when the work has been completed and your product has been installed.
Some manufactures may charge a small convenience fee if balance is paid by credit or debit card.To include installation at these prices we can only install the product the week we are installing products in your area, which could be on a two to four week rotation, depending the work level in the exact area of the installation. We will try to get your product installed as soon as possible. Installation delays may occur and will not justify a refund. No Exceptions.
